400KVA Oil Immersed Distribution Transformer Safe Operation For Agriculture

Brand Name : HENGFENGYOU

Model Number : S-11

Certification : ISO IEC CB COC KEMA SNI SABS CCC

Place of Origin : China

MOQ : 1

Price : 200-200000/piece

Payment Terms : LC T/T

Supply Ability : 5000 pieces/year

Delivery Time : 15 DAYS

Packaging Details : wooden case

Standard : IEC60076, GB1094-1996; JB/T10088-2004; GB/T6451-2008

Output voltage : 220V 380V 400V

Coil Structure : Toroidal

Vector group : Dyn11,Dyn5,Yyno or others

Rated capacity : 50,63,80,100,125,200,250,315,400,500,800,1000, 2000,2500, 3

Material : Copper or aluminum

Noise : 20

Load Loss : 976

Contact Now

Pole Mounted 10kv Three phase oil-immersed power transformers

S-9 series power transformer core USES the high quality cold-rolled steel coil, USES the high

quality anaerobic copper into and beautiful outlook, safety of operation. S9 series transformer

and compared, and the annual average no-load loss is reduced by 10% and the average load

loss is reduced by 20% and save energy obviously, widely used in industry and agriculture,

urban and rural power grid.

400KVA Oil Immersed Distribution Transformer Safe Operation For Agriculture

Rated capacity Voltage Combination Loss(kw) No-load current (%) Impedance voltage (%) Weight(kg)
(KVA) High voltage (KV) High voltage tapping range Low voltage(KV) Load No-load Oil weight Overall weight
10 6KV
6.3KV
6.6KV 10KV 11KV 13.8KV
 ±5%±2×2.5%

0.38kv

0.4kv

0.415kv

 0.26 0.09 3.2 4 45 172
20 0.44 0.1 3 57 230
30 0.6 0.13 2.3 75 295
50 0.87 0.17 2 88 395
63 1.04 0.2 1.9 95 420
80 1.25 0.25 1.9 103 480
100 1.5 0.29 1.8 115 540
125 1.8 0.34 1.7 130 645
160 2.2 0.4 1.6 145 740
200 2.6 0.48 1.5 175 885
250 3.05 0.56 1.4 195 1010
315 3.65 0.57 1.4 230 1205
400 4.3 0.8 1.3 255 1375
500 5.1 0.96 1.2 285 1620
630 6.2 1.2 1.1 4.5 350 1960
800 7.5 1.4 1.1 405 2310
1000 10.3 1.7 1 490 2690
1250 12 1.95 1 550 3315
1600 14.5 2.4 0.8 625 3985
2000 18 2.6 0.7 745 4520

400KVA Oil Immersed Distribution Transformer Safe Operation For Agriculture

400KVA Oil Immersed Distribution Transformer Safe Operation For Agriculture
